OPTIONAL MATERIALS OF CONSTRUCTION

UPPER HOUSINGS (Non-Wetted Material)

• 304 SS (304)
• Carbon Steel CS
• 316 SS (316)
• Monel 400 M4

LOWER HOUSINGS (Wetted Material)

• 304 SS (304)
• Inconel 600 (INC)
• 304L SS (304L)
• Inconel 625 (I625)
• 316 SS (316)
• Monel 400 M4
• 316Ti SS
• Nickel 200 (NICK)
• Carbon Steel CS
• Tantalum (TANT)
• Carpenter 20 (C20)
• Titanium GR.4 (TIT)4
• Hast-C22 (HC22)
• Teflon-25%GF (TFGF) (1500F max.)
• Hastelloy B-2 (HASB)
• Hastelloy C-276 (HAST-C)

DIAPHRAGMS (Wetted Material)

• 304L SS (304L)
• Silver (SILV)
• 316L SS (316L)
• Tantalum (TANT)
• 321 SS (321)
• Teflon Coated Metal
• Carpenter 20 (C20)

• Gold (GOLD)
• Titanium GR4 (TIT)4
• Hast – C22 (HC22)
• Zirconium 702 (ZIRC)
• Hastelloy B-2 (HASB)
• Buna N (NBR) (1250 PSI; 2500F)
• Hastelloy C-276 (HAST-C)
• Kalrez 1050LF (KALR)
• Inconel 600 (INC)
• Kel-F (KELF) (1250 PSI; 4000F)
• Monel 400 M4
• Teflon (TFE) (1250 PSI; 3500F)
• Nickel 200 (NICK)
• Viton A (VIT) (1250 PSI; 3500F)
• Nickel 201 (N201)

GASKETS

• Grafoil (GRAF)
• Non-Asbestos (4401)
• PTFE (3510) (-400F to 2000F)
• PTFE (K2) (-500F to 4500F)

O-RINGS

• Buna N (NBR) (-100F to 2500F
• Kalrez (KALR)
• Teflon (TFE) (-400F to 3500F)
• Viton A (VIT) (-100F to 3500F)

FEATURES

PEW features the most complete line of diaphragm seals available. Our capacity to handle even the most customer

Requirements  makes "PEW" The Wise Choice of diaphragm seal manufacturers.

The standard PEW line offers more than 45 types of process connections, as well as some classes of diaphragms; because one size diaphragm does not fit every application.

On-time delivery and meeting our customers' needs for rush orders are our priority at PEW Largest and most experienced engineering team in the industry designs  PEW for accuracy, stability and reliability   Material traceability and material certifications available  We are experts at working with special designs and material requirements.

Our experience is vast, our innovation legendary, and our commitment to our clients unwavering.

We look forward to working with you!

FLUSH CONNECTION:

Usually a 1/4 NPT connection in the lower housing that facilitates purging of the diaphragm seal process cavity.

LOWER HOUSING:

The portion of the diaphragm seal on the process side of the diaphragm that contains the process media (a wetted part).

UPPER HOUSING:

The portion of the diaphragm seal on the instrument side of the diaphragm that houses the fill fluid. Usually a non-wetted part.

WETTED:

Comes into direct contact with the process media

Techinfo Drawing

WE ARE ALSO MANUFACTURING -

FOR SENSOR

• PROCESS HEADERS-SS316/SS304/
• VENT HEADERS-SS316/SS304/
• TRI CLAMPS
• DIP TUBE ASSEMBLY
• JET SPRAY
• FLOW CHAMBER
• AIR HEADERS
• THERMOWELLS
• SPECIAL SEAL SEPRATOR
• CONDENSATE  POT [ CATCH POT]
